ONV H3108PFS 10 Ports Full Gigabit PoE Switch, 10port poe switch
The ONV H3108PFS 10 Ports Full Gigabit PoE Switch is a 10-port full gigabit PoE switch that is perfect for small businesses and home offices. It provides up to 30 watts of power per port, so you can easily connect and power your PoE devices, such as IP cameras, wireless access points, and VoIP phones.
FEATURE
Full gigabit rate, dual RJ45 ports uplink
◇ Support IEEE 802.3x full-duplex flow control and Backpressure.
◇ Support non-blocking wire-speed forwarding for smoother transmission.
◇ Provides Gigabit Ethernet ports and dual RJ45 ports uplink for flexible networking and meets the networking requirements of various scenarios.
Intelligent PoE power supply
◇ IEEE802.3af/at PoE standard, without damaging non-PoE devices.
◇ 8*10/100/1000Base-T RJ45 ports, meeting the needs of security monitoring, teleconferencing system, wireless coverage, and other scenarios.
◇ Priority system for PoE port, it will supply power to the high priority level port first when the power budget is insufficient and avoid overwork of the device.
Stable and reliable, easy to use
◇ CCC, CE, FCC, RoHS.
◇ Plug and play, no configuration, simple and convenient.
◇ Low power consumption, galvanized steel casing, no fan.
◇ The user-friendly panel can show the device status through the LED indicator of PWR, Link, PoE.
◇ Self-developed power supply, high redundancy design, providing a long term and stable PoE power output.
TECHNICAL SPECIFICATION
| Model | ONV-H3064PS | ONV-H3108PS |
| Interface Characteristics | ||
| Fixed Port |
4*10/100/1000Base-T PoE ports (Data/Power) 2*10/100/1000Base-T uplink RJ45 ports (Data) |
8*10/100/1000Base-T PoE ports (Data/Power) 2*10/100/1000Base-T uplink RJ45 ports (Data) |
| Ethernet Port | Port 1-6/ Port 1-10 support 10/100/1000Base-T auto-sensing, full/half duplex MDI/MDI-X self-adaption | |
| Twisted Pair Transmission |
10BASE-T: Cat3, 4, 5 UTP(≤100 meters) 100BASE-TX: Cat5 or later UTP(≤100 meters) 1000BASE-T: Cat5e or later UTP(≤100 meters) |
|
| Chip Parameter | ||
| Network Protocol |
IEEE802.3 10BASE-T, IEEE802.3i 10Base-T IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T, IEEE802.3x |
|
| Forwarding Mode | Store and Forward(Full Wire Speed) | |
| Switching Capacity | 16Gbps (Non-blocking) | 20Gbps (Non-blocking) |
|
Forwarding Rate@64byte |
8.93Mpps | 14.88Mpps |
| MAC | 8K | 2K |
| Buffer Memory | 2M | |
| Jumbo Frame | 9.2k | |
| LED Indicator | Power: PWR (Green), Network: Link (Green), PoE: PoE (Green) | |
| PoE & Power Supply | ||
| PoE Port | Port 1 to 4 | Port 1 to 8 |
| Power Supply Pin | 1/2(+) 3/6(-) | |
| Max Power Per Port | 30W, IEEE802.3af/at | |
| Total PWR / Input Voltage | 65W/ (AC100-240V) | 120W/ (AC100-240V) |
| Power Consumption | Standby <5W, Full load <65W | Standby <6W, Full load <120W |
| Power Supply | Built-in power supply, AC100~240V 50-60Hz 1.1A | Built-in power supply, AC100~240V 50-60Hz 2.2A |
| Physical Parameter | ||
| Operation TEMP / Humidity | -20~+55°C, 5%~90% RH Non condensing | |
| Storage TEMP / Humidity | -40~+75°C, 5%~95% RH Non condensing | |
| Dimension (L*W*H) | 140*115*40mm | 195*130*40mm |
| Net /Gross Weight | <0.6kg / <1.0kg | <0.9kg / <1.2kg |
| Installation | Desktop, Wall-mounted | |
| Certification & Warranty | ||
| Lightning Protection | Lightning protection: 4KV 8/20us, Protection level: IP30 | |
| Certification | CCC, CE mark, commercial, CE/LVD EN62368-1, FCC Part 15 Class B, RoHS | |
| Warranty | 1 year, lifelong maintenance. | |
ONV H3108PFS 10 Ports Full Gigabit PoE Switch
The ONV H3108PFS 10 Ports Full Gigabit PoE Switch is a full gigabit unmanaged PoE switch created separately by ONV. It contains 8 10/100/1000Base-T PoE ports and 2 RJ45 uplink 10/100/1000Base-T ports. IEEE802.3af/at PoE standard may be supported by ports 1-8. PoE power up to 30W per port. As a PoE power supply device, ONV H3108PFS 10 Ports Full Gigabit PoE Switch can detect and recognize power receiving equipment that complies with the standard and deliver power via the network cable. To meet the network environment that requires high-density PoE power supply, it can deliver power to POE terminal equipment such as wireless AP, camera, VoIP phone, video access control intercom, and so on through network cable. It is appropriate for hotels, universities, manufacturing units, and small and medium-sized businesses to build an economical network.
What is the price of the ONV H3108PFS 10 Ports Full Gigabit PoE Switch in Bangladesh in 2023?
The latest price of the ONV ONV H3108PFS 10 Ports Full Gigabit PoE Switch 8000 BDT. You can buy this ONV H3108PFS 10 Ports Full Gigabit PoE Switch us at the best price. You can either buy it through our website or directly visit our office
