Description
Model |
TVT TD-7524TM3 2MP Full-color HD Turret Camera |
| Camera | |
| Image Sensor | 1 / 2.8″ CMOS |
| Resolution | 2MP |
| Image Size | 1920 x 1080 |
| Video Output | AHD / TVI /CVI/CVBS |
| Image System | PAL / NTSC |
| Electronic Shutter | Auto TVT TD-7524TM3 2MP Full-color HD Turret Camera |
| LED Distance | 20 ~30 m |
| Frame Rate | 30fps(60Hz); 25fps (50Hz) |
| Min. Illumination | 0 lux (LED ON) |
| Lens | 3.6 mm (2.8mm optional) |
| Lens Mount | M12 |
| S / N Ratio | ≥52dB ( AGC OFF ) |
| Ingress Protection | IP 67 |
| Functions | |
| Function Control | OSD ( COC Control ) |
| Smart LED | Manual or Auto mode |
| ICR | NO |
| Digital WDR | Yes |
| 2D/3D DNR | Yes |
| AGC | Yes |
| Global Exposure | Yes |
| Central Exposure | Yes |
| Auto White Balance | Yes |
| BLC | Yes |
| Front Light Compensation | Yes |
| Contrast | Yes |
| Saturation/Color Gain | Yes |
| Sharpness | Yes |
| Image Setting | Yes |
| Defect Correction | Auto |
| Language | Chinese and English TVT TD-7524TM3 2MP Full-color HD Turret Camera |
| Angle Adjustment | Pan: 0°~360°; Tilt: 0°~75°; Rotation: 0°~360° |
| Others | |
| Power Supply | DC12V ( ± 15% ) |
| Power Consumption | IR OFF : < 1W; LED ON : < 3W |
| Working Environment | – 30 °C ~ 50 °C, 10 % ~ 90 % (relative humidity) |
| Dimensions ( mm ) | Ф 94.6 x 82.8 |
| Weight ( net ) | Approx. 0.39KG |
