16 Port PoE Switch Jovision JVS-S18-16P-240W Best Price in Bangladesh
JVS-S18-16P-240W 1000M uplink POE switch provides 16 10/100m adaptive RJ45 ports and 2 10/100/1000M adaptive RJ45 ports. Ports 1 to 16 provide POE power supply and can serve as Ethernet power supply devices.
All POE ports can automatically detect and identify electrical devices that comply with IEEE 802.3af/at standards and supply power to them through network cables.
This model supports intelligent AI detection. When the monitoring device crashes or the network is abnormally interrupted, the AI algorithm is used to determine the intelligent restart of the POE port device.
Automatic network optimization: automatically judge the status of network signal transmission, intelligent switch remote mode, long-distance transmission is stable without disconnection.
16 Port PoE Switch Product Characteristics:
• Comply with IEEE 802.3U And IEEE 802.3U Fast Ethernet protocol standards;
• Support IEEE 802.3AF/AT standard, compatible with PD that supports IEEE 802.3AF/AT
• Supports common switch/automatic AI detection + AI remote (combined function) dual-mode
• Provides 16 10/100m adaptive POE power ports and 2 uplink 10/100/1000M adaptive RJ45 ports
• All ports support the Auto MDI/MDI-X function
• Supports IEEE 802.3x full-duplex flow control and Backpressure half-duplex flow control
• All ports have wire-speed forwarding capability
• Supports MAC address self-learning and aging
• Full metal casing, full load 240W
• Plug and play
Software Specifications:
• Complies with IEEE 802.3 Ethernet and IEEE 802.3u Fast Ethernet protocol standards
• Compliant with IEEE 802.3af/at standards for receiving devices (PD)
• Compatible with certified non-standard electrical receiving equipment (PD)
• Store and forward
• MAC automatic learning and aging
• IEEE 802.3x full-duplex flow control and Backpressure half-duplex flow control
16 Port PoE Switch Hardware Specifications:
Port | 100M PoE | 16 |
1000M Cascade RJ45 | 2 | |
Function | Storage and Forwarding | Support |
Exchange Content | 7.2G | |
MAC Address | 2K | |
Use Environment | Working temperature: 0 ℃ ~ 40 ℃Storage temperature: -40 ℃ ~ 70 ℃ | |
Working humidity: 10% ~ 90% RH does not condense Storage humidity: 5% ~ 90% RH does not condense | ||
PoE Standard | Standard IEEE802.3af/at single port maximum power 30WSupport overcurrent, overvoltage, short-circuit protection Support for High Power PD soft start Support sequential boot | |
Input Power Supply | AC input 100-250V, standard 200W/240W power supply | |
Supported Standards & Protocols |
IEEE 802.3 Ethernet Media access Control Protocol IEEE 802.3i 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet IEEE 802.3af implements power supply for Ethernet devices through Ethernet data cable pairs or devices IEEE 802.3at implements high power supply for Ethernet devices through Ethernet data cable pairs or devices IEEE 802.3x flow control |
|
System Mode | OFF: Default working mode ON: Extend +AI | |
Data Signaling Rate | Ethernet 10Mbps half-duplex, 20Mbps full duplex Fast Ethernet 100Mbps half-duplex, 200Mbps full duplex Gigabit Ethernet 2000Mbs full duplex | |
Network Medium |
1000Base-T: 4 pairs Cat5e or more UTP/STP(≤100m) 100Base-TX: 2 pairs Cat5 or more UTP/STP (≤ 100m) 10Base-TX: 2 pairs Cat5 or more UTP/STP (≤ 250m) |
|
Physical Specification | Product size: 270mm*180mm*45mm (L*W*H) |
What is the price of 16 Port PoE Switch Jovision JVS-S18-16P-240W Switch in Bangladesh?
The latest price of 16 Port PoE Switch Jovision JVS-S18-16P-240W Switch in Bangladesh is 15,600৳. You can buy the 16 Port PoE Switch Jovision JVS-S18-16P-240W Switch at best price from our website or our showrooms.
