Specification of the HIKVISION iDS-7216HQHI-M1-S 16-channel DVR
| Audio And Video | |
| Audio and Video | IP Video Input : 8-ch (up to 24-ch); up to 6 MP resolution;Support H.265+/H.265/H.264+/H.264 IP cameras Analog Video Input : 16-ch; BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection HDMI Output : Yes CVBS Input : PAL/NTSC CVBS Output : 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 Synchronous Playback : 16-ch AHD Input : 4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps HDCVI Input : 4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps Audio Output : 1-ch, RCA (Linear, 1 KΩ) Audio Input : 1-ch, RCA (2.0 Vp-p, 1 KΩ) Two-Way Audio : 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input) |
| Recording | Video Compression : H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 Encoding Resolution : 4MP Video Bitrate : 32 Kbps to 6 Mbps Dual-Stream : Support Stream Type : Video, Video & Audio Audio Compression : G.711u Audio Bitrate : 64 Kbps |
| Network | Network Protocol : TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnPTM, HTTPS, and ONVIF Remote Connection : 128 Network Interface : 1×Gigabit |
| Power Specifications | |
| Power | Power Supply : 12 VDC |
| Main Features | |
| Auxiliary Interface | SATA : 1 SATA interface Capacity : Up to 10 TB capacity for each disk Serial Interface : RS-485 (half-duplex) USB Interface : 1 × USB 2.0, 1 × USB 3.0 Alarm In/Out : No |
| Physical Specification | |
| Dimensions | 315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch) ≤ 2 kg (4.4 lb) |
| Warranty | |
| Manufacturing Warranty | 01-year warranty |
| Other Features | |
| Others | Consumption : ≤ 24 W Working Temperature : -10 °C to +55 °C (+14 °F to +131 °F) Working Humidity : ≤ 24 W Chassis : 1U (315mm) |
| Shipping Cost |
|
| Shop Location | Dhaka, Dhaka, Bangladesh |
